Natural Tire Tube Flap 16/70-20

1) Truck tire flaps (such as 750/825-16, 900-20, etc.)

2) Engineering machinery tire flaps (such as 23.5-25, 1400/1600-25, etc.)

3) Agricultural tire pads (such as 15-24, 400-16, etc.)

4) Industrial vehicle tire pads (such as 300-15, etc.)
5) Handcart tire flaps (such as 400-8, etc.) meet the needs of different vehicles and equipment.

The main material of INKLIDA flaps is generally natural rubber, which should have good elasticity, wear resistance, and aging resistance. The additives such as carbon black, zinc oxide, etc. should be accurately selected and proportioned according to the product performance requirements to ensure the processing performance of the rubber material and the final product quality.

Natural rubber is approximately 15%, carbon black is 5%, natural recycled rubber is 70%, and other components are 10%. Capable of withstanding high temperatures of 70-120 degrees Celsius

Appearance quality: No appearance defects that affect the service life are allowed, and other appearance quality requirements should comply with the provisions of HG/T 2177.
Physical properties: Tensile strength ≥ 7.0MPa, elongation at break ≥ 350%, permanent deformation at break ≤ 40%, hardness (Shore A type) between 55 and 75 degrees.
Main dimensions of finished products: The flat width, middle thickness, and edge thickness of tire pads of different specifications are clearly defined. For heavy-duty truck tire pads with specifications of 8.25-15, the flattened width is ≥ 175 millimeters, the middle thickness is ≥ 4.0 millimeters, and the edge thickness is ≤ 1.5 millimeters.

Our Natural Tire Tube Flap 16/70-20 have strictly quality control. There will be 3 times of filtration of raw material and 3 times inspection of products before leave the factory. Every inner tube or tire flaps is produced and inspected strictly piece by piece. Our all products will be inspected with air inflation for 24 hours.
